Metrici LED Display RGB128x64
Programmable RGB LED matrix display
Specifications
- Resolution
- 128 × 64 pixels
- LED colors
- RGB
- Features
- It can show 1, 2 or 3 rows of text with up to 12 characters each. All parameters can be changed from its own web interface.
- Dimensions
- 65.5 × 33.5 × 8 cm
- Networking
- WiFi and 10/100 Ethernet
- Protocol
- HTTP over TCP/IP
- Software compatibility
- Metrici2 v3.1 and above
- Power requirements
- 350 W
- Working temperature
- −20 to +50 °C, IP66
- Weight
- 6 kg
- Case
- Heavy-duty aluminium, 4 mounting holes (2 top and one on each side), backplate with isolated I/O connectors
Examples
